GK64 Brass Plate(GH60 XD64 DZ60 GK64 Gk64x GK64xs Using/Plate Mounted)

Package Included(GK64 Brass Plate)

GK64 Brass Plate For 60%(+Stabs)

Details

This is the plate for GK64 kit,can use it as the replacement for GK64 of plastic kit.And can still use it in GH60 case with GK64/YD60MQ PCB etc to do a new keyboard with standard 2u shift 64 layout.

If you choose stabilizers kit,there will be 1x6.25u + 3x2u which is enough for 64 keyboard.And it only support plate mounted stabs now for the plate.

Brass plate is PVD sand blasted.The hardness and sound is better than steel plate.

The OEM plate stabilizers is more smooth but bigger noise,genuine Cherry stabilizers is more silent.

Compatibility

To use on old GK64 GK64s,can attach PCB to plate with 3 screws.Or just attach with switches.It can't use in original GK64 plastic case.Need to replace a GH60 size case

To use on new GK64x GK64xs,PCB and plate can attach with all screws.Or just attach PCB plate by switches is ok as well

To use on GH60 PCB (64 layout),such as DZ60 YD60M OK60 XD60.

How to Mount with GK64/GK64x/GK64xs PCB

1.Mount 4 switches to plate in 4 corners and then plug to PCB

2.After 4 switches mounting propler,the plate PCB will be stable,then mount other switches onto plate PCB is ok

3.Mount PCB plate together to Gh60 size case

Layout support

Images Display
